Overview

Basic Info.

Model NO.	GR100-PNS-DIO32D-B
Function	Automatic Control
Certification	ISO: 9001, CE
Condition	New
Customized	Customized
Product Name	PLC Coupler Module
Warranty	12 Months
MOQ	1PCS
Service	OEM.ODM
Quality	100% Strictly Tested
Transport Package	Carton Package
Specification	50*98*94mm
Trademark	LicOS
Origin	China
Production Capacity	50000 Pieces/Year

Product Description

UnionScience Technology Group Co., Ltd. was founded in 2000, is a high-tech enterprise focusing on industrial controller research and development and industrial Internet development. Then, we are a manufacturer with a research and development center and are now launching our brand LicOS, moreover, we support OEM and ODM. We also possess many certifications to ensure products' safety and quality, such as, CE certifications, ISO series certifications

In the LicOS PLC and PAC product family, UnionScience has launched EC300 series small and medium-sized PLC, EC400 series large PLC, MC600 series PAC, GL100 series distributed IO system, covering nearly 100 types of CPU modules, remote communication modules and IO modules. It meets the application requirements of logic control, sequence control, process control, motion control, edge intelligence and other industrial control scenarios, and has been widely used in transportation, logistics, chemical industry, new energy, machinery, high-end equipment manufacturing and other fields, providing personalized solutions for the automation field.
We sincerely welcome friends from all over the world to visit our company and cooperate with us on the basis of long-term mutual benefits. We are looking forward to receiving your enquiry soon.

Q1: Are you trading company or manufacturer?

We are manufacture. We can give you one-stop station automation purchasing.

Product Description

Product Name	PLC coupler module
Model	GR100-PNS-DIO32D
Brand	LicOS
Place of Origin	Yunnan,China
Condition	100% New 100% Original
Series	GR100 series
Core Points	★1: The input channel supports both source/drain input and drain output. ★2: ON response time: <=0.5ms ★3: OFF response time: <=0.5ms ★4: Number of slaves: up to 127.
Technical Consulting Support	Yes
Warranty	1 year

Product Parameters

Type	Profinet coupler module		EtherCAT coupler module
Product model	GR100-PNS-DIO32D-B	GR100-PNS-DIO32S-B	GR100-TCS-DIO32D-B	GR100-TCS-DIO32S-B	GR100-TCS
Communication mode	Profinet		EtherCAT
Supply voltage	24VDC(-15%~20%)
Input Chanel	2-way 10M/100M adaptive Ethernet interface
Transmission medium	Category 5 twisted pair
Electrical isolation	500Vrms Power supply voltage/fieldbus
Current consumption	100mA@24VDC
Module Scan	Expandable to 16 GL100 series IO modules	Expandable to 16 GL100 series IO modules	Expandable to 16 GL100 series IO modules	Expandable to 16 GL100 series IO modules	Expandable to 16 GL100 series IO modules
Diagnostic Information	Communication diagnosis, data diagnosis, configuration diagnosis
Communication rate	100Mbit/s (100BASE-TX)
IO Chanel	integrated 16 DI(PNP/NPN), 16 DO NPN	integrated 16 DI(PNP/NPN), 16 DO NPN	integrated 16 DI(PNP/NPN), 16 DO NPN	integrated 16 DI(PNP/NPN), 16 DO NPN	/
Communication rate	100Mbit/s(100BASE-TX)
transmission mode	full duplex
topological structure	Bus, Star, Ring, Tree, Hybrid Topology
transmission distance	100m Station-Station distance
Number of slave stations	127 maximum

Feedback

Certifications

Company Profile

FAQ

Q2: ls there any engineer can help for technical supporting? Sure, we have. Our technical team can help you for selecting PLC, Servo motor & drive, VFD(Variable Frequency Drive), Inverter, and so on. If you need any help, you can contact our technical department directly. Q3: Do you support customization? Yes, we do. We support products customization, such as, logo customization, package customization, and so on.
Q4: Do you supply 100% original and new products? Of course, yes. No copy, no fake, no refurbished! Original only! Q5: How long is your leading time? Generally 2-3 working days if the goods are in stock. If large quantity, it will take 10-15 working days after getting the payment. If not common products, always need 3-4 weeks or 6-8 weeks to order. Q6: How long is your delivery time? It's up to your order quantity and shipping channels choices. We have many cooperatives shipping channels, such as, by sea, by express, by air, by land, and so on. If your order quantity is less, we could ship the package out by express, the delivery time just needs 3-7 days.If your order quantity is large, we could ship the package out by sea, the delivery time is about 25-45 days.Other shipping channels delivery time is about 15-25 days. Q7: Do you support samples? Yes, we support partial products samples. Q8: Do you support after sale warranty service? Yes, we support after sale warranty service within 1 year. All fees depends on the actual situation.
