Overview

Basic Info.

Material	Plastic, ABS Plastic + Electronic Components
Transport Temperature	-20ºC~55ºC
Work Humidity	10%-95% (No Condensation)
Warranty	2 Years
Power Supply Mode	Removable Battery
Transport Humidity	10%-95% (No Condensation)
Classification	Diagnosis and Monitoring Equipment
Function	Diagnose
Power Supply	Dry Batteries
Power Source	Electricity
Transport Package	Carton
Specification	9*6*4cm
Trademark	Konsung
Origin	Danyang
HS Code	9018199000
Production Capacity	5000 Pieces Per Month

Product Description

Product Description

Color OLED display, four direction adjustable.

SPO2 and pulse monitoring, waveform display.Low-power consumption, continuously work for 50 hours.

Small in size, light in weight and convenient to carry.

Low voltage alarm display, auto power-off

Runs on standard AAA batteries.

High quality products from high quality parts.
Product Parameters

Model	SONOSAT-F02T
Working Environment
Types of electric shock protection	Dry betteries
Anti-electric shocks degree	BF type
Work Humidity	15%-85% (no condensation)
Transport Humidity	10%-90% (no condensation)
Transport Temperature	5-40ºC
SPO2
Measuring Range	70-99%
Accuracy	±2% on the stage of 70%-99%
Resolution	1%
Low perfusion	<0.4%
Pulse Rate
Measuring Range	30-240bpm
Accuracy	±1BPM or ±1% (the larger one)
Power	two AAA 1.5V alkaline batteries
Power consumption	<30mA
Automatic power-off	the products shut down automatically
After no signal	8s
PI
Perfusion Index Display	0-30%
Packing Information
Packing Size	40×37×24cm, 40pcs/carton
G.W./N.W.	0.15/0.12kg

Configuration

NO.	Description	Qty (pcs)
1	Pulse oximeter	1
2	Sling	1
3	Instruction	1
4	Protection to fix card	1
